Causes of Uneven Wall Thickness:

• Parison Core Deviation: The gap between the mandrel and die in the blow molding machine‘s die head is uneven.
• Mold Misalignment: The mold is misaligned with the die head center.
• Parison Control Issues: For machines with a “wall thickness control system,” improper program settings or a servo valve malfunction may occur.
• Raw Material Issues: Insufficient melt strength causes the parison to sag and stretch unevenly due to its own weight.

When encountering uneven wall thickness, follow these troubleshooting steps:

Step 1: Static Parison Inspection

• Allow the extrusion blow molding machine to extrude the parison normally, but without closing the mold or blowing air.

• Observation: Is the parison round? Is there any noticeable deviation to one side? Measure the circumferential thickness of the parison by hand or with a gauge.
• Conclusion: If the parison is uneven at rest, the problem is 100% with the die head (concentricity, temperature, or blockage).

Step 2: Check the Wall Thickness Control Curve

If the parison is uniform at rest, but the wall thickness of the product is uneven,

• Action: Check the curve set in the wall thickness control program for accuracy. Try running a “flat” curve (i.e., no control) to see if the part’s wall thickness becomes uniform (although the axial distribution may be incorrect).
• Conclusion: If the part is uniform circumferentially under a flat curve but has poor axial distribution, the problem lies with parison sagging or the wall thickness curve. If circumferential unevenness persists under a flat curve, the problem may lie with mold alignment or the inflation process.

Step 3: Check the Mold and Blowing Process

• Check the mold alignment.
• Check the blow needle for correct positioning to avoid scraping the parison and causing thinning.
• Observe the mold closing and blowing process to see if the parison is distorted.

Step 4: Check the Raw Materials and Process

• Verify that the raw materials are dry and clean.
• Verify that the processing temperature is within the recommended range to avoid excessive temperatures.
