This laundry detergent liquid bottle manufacturing machine is suitable for the production of 200ML-10L plastic hollow products. This laundry detergent bottle manufacturing machine adopts bending elbow locking system, low energy consumption, central locking, locking force, fast speed, more stable operation.
1. Opening and closing mold system: specially designed to balance type mold locking mechanism, the use of high pressure mold locking, lock template force in the center of the template, mold locking force is large, open solid lock template, even super wide mold also installed under.
2. Die head system: are made of 38CrMaALA and other superior materials, after precision machining and heat treatment.
3. Hydraulic system: full hydraulic pressure double proportion hydraulic control, stable, reliable.
4. Automatic fly-edge device of bottle blow molding machine: the overflow device can accurately cut the residual material of the product, and it is equipped with direct push overflow device and rotary knife overflow device.
5. Control system: The blow molding machine adopts PLC man-machine interface (Chinese or English) control, touch screen operation, process setting, change, retrieval, monitoring, fault diagnosis and other functions can be realized on the touch screen. Easy to operate.
Article | 500ml Inclined Neck Bottle |
---|---|
Diehead | 6-Fold Extrusion Head |
Layer | Deco 2-Layer |
Double/Single Stations | Double Station |
Net Weight | 53±1.5g |
Cycle Time | 18 Seconds |
Article Output Per Hour | 2400 Pcs/Hour |
Machine Type | B20D-1050 |
